Model |
EMF-3.5 (Digital) |
EMF-3.5 (Program) |
|
Temp Range |
Max. 1100°C | |
|
Working Temp |
300 ~ 1000°C | |
|
Temp control |
Digital PID controller |
LCD Program controller. |
|
Timer |
99hr 59min | |
|
Thermo couple |
K-type | |
|
Output Regulator |
SSR unit controller | |
|
Insulation |
Ceramic Board |
Ceramic Fiber |
|
Heating element |
Kanthal A1(exposure) | |
|
Heater Capacity |
2.2 KW | |
|
Chamber Capacity |
3.5 Liter | |
|
In Size (W×D×H)mm |
140 x 140 x 180 | |
|
Out Size (W×D×H)mm |
400 x 500 x 970 | |
|
Safety Device |
Over Temp protector, Power breaker | |
|
Power |
AC 220V, 1Ø, 50/60 Hz | |
