Model |
SF-4.5 |
SF-11 |
SF-22 |
MSF-4.5 |
MSF-11 |
MSF-22 |
|
Temp Range |
max. 1450℃ |
max. 1650℃ |
||||
|
Working Temp |
500~1400℃ |
500~1600℃ |
||||
|
Temp control |
Microprocessor program controller (2 pattern 10 segment) |
Microprocessor program controller (2 pattern 10 segment) |
||||
|
Thermocouple |
R-type |
B-type |
||||
|
Output Regulator |
SCR unit controlle |
SCR unit controller |
||||
|
Heating element |
SIC 2 heate |
Mosi2 Heater |
||||
|
Heater Capacity |
3.3 KW |
7.7 KW |
9.6 KW |
3 KW |
6.6 KW |
9.5 KW |
|
Capacity |
4.5 Liter |
11 Liter |
22 Liter |
4.5 Liter |
11 Liter |
22 Liter |
|
Insulation |
Ceramic Board (1600°C , 1400°C , 1200°C ) |
Ceramic Board (1800°C , 1600°C , 1200°C ) |
||||
|
안전 장치 |
자기 진단 기능(과열 방지 장치, 센서 단선), 과전류 Breaker, A/V-meter |
|||||
|
외부 규격 (W x D x H)mm |
820 W |
870 W |
920 W |
920 W |
980 W |
1050 W |
|
560 D |
630 D |
710 D |
610 D |
680 D |
750 D |
|
|
660 H |
730 W |
850 H |
770 H |
840 H |
910 H |
|
|
nternal Dimension (L x D x H) (mm) |
150 x 200 x 150 |
200 x 270 x 200 |
250 x 350 x 250 |
150 x 200 x 150 |
200 x 270 x 200 |
250 x 350 x 250 |
|
External Dimension (L x D x H) (mm) |
820 x 560 x 660 |
870 x 630 x 730 |
920 x 710 x 850 |
920 x 610 x 770 |
980 x 680 x 840 |
1050 x 750 x 910 |
|
Power supply |
AC 220V, 1 Ø 50/60Hz Industrial Plug |
AC 220V, 1 Ø, 50/60Hz Industrial Plug |
||||
