Model |
DMF-3 |
DMF-4.5 |
DMF-12 |
PMF-14 |
DMF-27 |
DMF-64 |
|
(program) |
PMF-3 |
PMF-4.5 |
PMF-12 |
PMF-14 |
PMF-27 |
PMF-64 |
|
Working Temp |
300°C ~ 1000°C |
|||||
|
Temp control |
Digital PID controller program type( 5Pattern 18 segment LCD program-PMF type) |
|||||
|
Timer |
99hr 59min |
|||||
|
Thermocouple |
K-type |
|||||
|
Materials |
Internal-Ceramic Fiber, External-Steel plate with powder coating. |
|||||
|
Insulation |
Ceramic Fiber/ceramic board |
|||||
|
Heater |
Kanthal A1, 4-side Heating |
|||||
|
Safety Device |
Over temp/Current protection, Sensor error detection Safety switch for opening. |
|||||
|
Power |
AC 220V, 1Ø, 50/60Hz |
|||||
|
Capacity |
3 Liters |
4.5 Liters |
12 Liters |
14 Liters |
27 Liters |
64 Liters |
|
Internal Dimension (L x D x H) (mm) |
130 x 250 x 90 |
150 x 300 x 100 |
200 x 300 x 200 |
250 x 350 x 160 |
300 x 300 x 300 |
400 x 400 x 400 |
|
External Dimension (L x D x H) (mm) |
390 x 480 x 550 |
420 x 540 x 570 |
480 x 550 x 680 |
550 x 590 x 620 |
580 x 590 x 780 |
1000 x 720 x 870 |
|
Heater capacity |
1.4 KW |
1.8 KW |
3.6 KW |
4 KW |
4.6 KW |
9 KW |
|
Net weight |
30 kg |
35 kg |
40 kg |
55 kg |
70 kg |
80 kg |
|
Power |
Standard Flug |
Industrial Plug |
||||
