MODEL |
P-THC-42 |
|
제품코드 No. |
100887 |
|
Capacity |
42 Liter |
|
In Size (W x D x H) (mm) |
350 × 350 × 350 |
|
Out Size (W x D x H) (mm) |
510 × 590 × 710 |
|
Number of Shelves |
2 EA, Shelf load Max, 15 Kg |
|
Heater Capacity |
1.8KW |
|
Convection method |
Forced convection method |
|
Temperature control range and Used rage |
0~60°C (10~60°C) |
|
Temperature control method |
LCD program controller, 5 patterns 18 segments |
|
Temperature distribution chart |
±2°C |
|
Humidity control range and Use range |
30~95% RH (35~90% RH) |
|
Humidity control method |
LCD program controller, 5 patterns 18 segments |
|
Humidity distribution chart |
±3% |
|
Inner material |
Stainless steel |
|
Outer material |
Powder coating at Iron |
|
Door packing |
Silicon |
|
Shelf pitch, No. Of shelf |
25 mm. |
|
Cable port |
Left Inner Body Inner diameter 38 mm |
|
Air-convection |
Tangent flow fan with AC-motor |
|
Refrigerators. refrigerants |
250 W, Air cooling unit system, R134A |
|
Safety device |
Over, Under temp. potector Level monitor, Power breaker |
|
Power input |
AC 220V, 60Hz, 1Ø |
