Model |
DI-13 |
DI-49 |
DI-91 |
DI-150 |
DI-250 |
|
|
Capacity |
13 Liter |
49 Liters |
91 Liters |
150 Liters |
250 Liters |
|
|
Internal Dimension (W x D x H) (mm) |
220 x 225 x250 |
350 x 400 x 350 |
450 x 450 x 450 |
500 x 500 x 600 |
500 x 500 x 1,000 |
|
|
External Dimension (W x D x H) (mm) |
325 x 400 x475 |
500×590×720 |
600×640×820 |
650×690×970 |
655×690×1350 |
|
|
Heater Capacity |
300 W |
300 W |
300W |
500W |
500W |
|
|
Shelves |
2 EA |
2EA |
2EA |
3EA |
3EA |
|
|
Type |
Forced Convection Type |
|||||
|
Temp |
Range |
주변온도 +10°C to 60°C |
||||
|
Controller |
Digital PID Controller (Control Sensitivity : ±0.1°C) |
|||||
|
Regulaor |
SSR Controller |
|||||
|
Thermocouple |
Pt-100Ω |
|||||
|
Timer |
Range |
99 Hr 59 Min |
||||
|
Controller |
Digital Display |
|||||
|
Material |
Internal Material |
Stainless Steel Plate |
||||
|
External Material |
Steel Plate With Poeder Coating |
|||||
|
Door Packing |
Double Door, Magnetic Gum packing |
|||||
|
Inner Door |
High temperature safety glass of thickness 5mm |
|||||
|
Shelves |
ABS coating (Adjustable Type) |
|||||
|
Safety Device |
Over Temperature Limit/Over Current Glass Fuse |
|||||
|
Supply Voltage &Frequencv |
AC 230V, 50/60Hz |
|||||
|
Power |
AC 220V, 50/60Hz 1Ø |
|||||
